Light Calculator
SIMPLE STEPS
1
Select our LED Fixture from our Website
2
Select the “Light Calculator” button
3
Configure your room layout and settings
4
Print / Link / E-Mail your finished layout
RGD-SP5 4" Slim Panel,98W (750lm), Selectable (27-30-35-40-50K), Dimmable, White, 120V, FT6 Cable, 90CRI, Metal trim
RGD-SP5/4/9W/MK5/WH/D
3662197
SSL-AL3, Area Light, Selectable 300-240-200W (39000-31200-26000lm), Type III, 22K, 120-347V, Black, SCR (Shorting Cap and Receptacle for PC)
SSL-AL3/T3/300M/MW/22/120-347V/BK/D/SCR
3682265
SSL-AL3, Area Light, Selectable 150-100-70W (19500-13000-9100lm), Type III, 22K, 120-347V, Black, SCR (Shorting Cap and Receptacle for PC)
SSL-AL3/T3/150S/MW/22/120-347V/BK/D/SCR
3680376
SSL-AL3 Area Light, 150S, Type III, Multi-Watt 150-100-70W, Multi-K 30-40-50K, 120-347V Auto-Sensing Driver, White, 0-10V Dim, SCR (Shorting Cap and Receptacle for PC)
SSL-AL3/T3/150S/MW/MK/120-347V/WH/D/SCR
3682258
Rigid Flush Mount II, 12", Fitable 22-18-15W (1540-1260-1000lm), Fitable 5CCT (27-30-35-40-50K), CRI 90, TRIAC Dimmable, 2 Ring
RGD-FM2/12/MW/MK/D/2R
3662188
RIGID 4" Commercial Down Light Regressed, High Output, Flexcable for Commercial ceilings, 13-10-8-6W, 1300/1000/800/600lm, 5 CCT, 120-347V, TRIAC & 0-10V Dim, ES
RGD-CDR/HO/4/MW/MK9/120-347V/WH/D
3682285
RIGID 6" Commercial Down Light Regressed, High Output, Flexcable for Commercial ceilings, 23-18-15-13W, 2300/1800/1500/1300lm, 5 CCT, 120-347V, TRIAC & 0-10V Dim, ES
RGD-CDR/HO/6/MW/MK9/120-347V/WH/D
3682286
RIGID 8" Commercial Down Light Regressed, High Output, Flexcable for Commercial ceilings, 34-30-27-24W, 3400/3000/2700/2400lm, 5 CCT, 120-347V, TRIAC & 0-10V Dim, ES
RGD-CDR/HO/8/MW/MK9/120-347V/WH/D
3682287
RIGID 10" Commercial Down Light Regressed, High Output, Flexcable for Commercial ceilings, 42-38-35-30W, 4200/3800/3500/3000lm, 5 CCT, 120-347V, TRIAC & 0-10V Dim, ES
RGD-CDR/HO/10/MW/MK9/120-347V/WH/D
3682288
Rigid Flush Mount II, 14", Selectable 24-21-18W (1800-1575-1350lm), Selectable 5CCT (27-30-35-40-50K), CRI 90, TRIAC Dimmable, 2 Ring
RGD-FM2/14/MW/MK/D/2R
3662189
ENDURA SP II, 4" Slim Panel, 8W (750lm), Selectable 5-CCT (27-30-35-40-50K), 120-347V, White, FT6 Cable, 80CRI, 0-10V Dimmable, ES
EDA-SP2/4/8W/MK5/120-347V/WH/0-10V
3682294
ENDURA SP II, 6" Slim Panel, 12W (1100lm), Selectable 5-CCT (27-30-35-40-50K), 120-347V, White, FT6 Cable, 80CRI, 0-10V Dimmable, ES
EDA-SP2/6/12W/MK5/120-347V/WH/0-10V
3682295
ENDURA SP II, 8" Slim Panel, 16W (1500lm), Selectable 5-CCT (27-30-35-40-50K), 120-347V, White, FT6 Cable, 80CRI, 0-10V Dimmable, ES
EDA-SP2/8/16W/MK5/120-347V/WH/0-10V
3682296
6pcs/pack, PRO-SP7 Slim Panel, Metal trim, 4", 8W (750lm), Selectable 27-30-35-40-50K, 120V Triac Dimmable, White, FT4 Cable, Wet Location.
PRO-SP7/4/8W/MK5/120/WH/D
3662194
RIGID HS Versatile Slim Flush Mount 5", 11W (700lm), Fitable 27-30-35-40-50K, TRIAC Dimmable, White trim
RGD-HS/VERS/5/11W/MK5/WH/D
3662200
