Light Calculator
SIMPLE STEPS
1
Select our LED Fixture from our Website
2
Select the “Light Calculator” button
3
Configure your room layout and settings
4
Print / Link / E-Mail your finished layout
SSL-LHB5 Linear Highbay 155M Selectable 155W-130W-105W (23250-19500-15750lm), Selectable 40-50K, 120-347V, Auto-Sensing Driver, AirCraft Cable Mtg., 0-10VDim, c/w 10' White Cord, LV Sensor Capable
SSL-LHB5/155M/MW/MK/120-347V/AC/D
3682216
RIGID HS Flush Mount, 4" Dia. 6W (420lm), 30K, Triac Dimmable, Energy Star, Surface Discus, White
RGD-HS/4/6W/30K/WH/D
3662161
SSL-XHC Round High Bay, 200W (27000lm), 347V, White Finish, 40K, 1-10V Dim, 90 Degree, 10' Cord, Hook, NEMA 4X, DLC Premium
SSL-XHC/200W/40/347V/HK/D
3667236
EDA-BOL B, Bollard no Lens Module, 6" Dia., MW 30-24-18W, MK 30-40-50K, 120-347V Auto-Sensing Driver, Black, 0-10V Dim. 44" OAH (when assembled)
EDA-BOL/B/CFIX/MW/MK/120-347V/BK/D
3682214B
RIGID VN Vanity Light, 2FT, 14W (1450lm), 30K, Dimmable, 2 Ring, Energy Star
RGD-VN/2F/14W/30/D/2R
3663123
DL-EC2 Strip Light 4ft. 56W (7280lm), Selectable 30-35-40-50-65K, 120-347V, Auto-Sensing Driver w/ Auxiliary LoVo 0-10V Dim
DL-EC2/4F/56W/MK/120-347V/D/A
3666323
SELECT 6" Slim Panel, Fire Rated (2Hr.), 15W, Selectable MK 5-CCT (27-30-35-40-50K), 120V, White, FT6 Cable, 90CRI, Triac Dimmable.
SEL-SP/FR/6/15W/MK5/120V/WH/D
3665321
RIGID HS Flush Mount 6" Dia. White, 12W (840lm), Surface Discus w/Magnet, Selectable CCT, Triac Dimmable, 120V, Energy Star
RGD-HS/6/12W/MULTI-K/WH/D
3662145
EDA-BOL A, Bollard Opal PC Lensed Module, 6" Dia., MW 30-24-18W, MK 30-40-50K, 120-347V Auto-Sensing Driver, Black, 0-10V Dim. 43" OAH (when assembled)
EDA-BOL/A/CFIX/MW/MK/120-347V/BK/D
3682213A
ENDURA 6" Slim Panel, 12W (1100lm), Selectable 5-CCT (27-30-35-40-50K), 120-347V, White, FT6 Cable, 80CRI, 0-10V Dimmable, ES
EDA-SP/6/12W/MK5/120-347V/WH/0-10V
3682204
RGD-BLP6 BackLit Panel, 2x2, S, Selectable 30-25-21W (3750-3125-2625lm), Selectable 35-40-50K, 120-347V, Auto-Sensing Driver w/ Auxiliary LoVo 0-10V Dim (100-1%)
RGD-BLP6/22/S/MW/MK/120-347/D
3682226
RGD-SP3 6" Slim Panel, 12W (930lm), Selectable (27-30-35-40-50K), Dimmable, White, 120V, FT6 Cable, 90CRI.
RGD-SP3/6/12W/MK5/WH/D
3662176
SEL-PS Strip Light, 4FT, Selectable 40W-35W-30W (5200-4550-3900lm), Selectable 35-40-50K, 120-347V, 0-10V Dimming
SEL-PS/4FM/MW/MK/120-347V/D
3680374
PRO-BLP3 Backlit Panel 2x2 Ultra slim, Selectable 40-30-25W (4400-3300-2750lm), Selectable 35-40-50K, 120-347V, Auto-Sensing Driver.
PRO-BLP3/22/MW/MK/120-347V/D
3682243
